FAIRINO FR10 - COBOT
Payload
10KG
Reach
1400mm
Repeatability
±0.05mm
COBOTS - The Fairino FR10 collaborative robot (cobot) redefines industrial automation with a perfect balance of power, precision, and safety. This next-level 6-axis robotic arm is engineered for versatility — capable of handling demanding tasks like machine tending, welding, and material handling while maintaining the finesse needed for delicate assembly and inspection. With a 10 kg payload, high repeatability, and intuitive programming.
Price :
$10,199.00
MTTR :
(Mean Time To Repair)
30,000 HR.
Specification | Payload | 10kg (Max:14kg) | |
Reach | 1400mm | ||
Degrees of freedom | 6 rotating joints | ||
HMI | 10.1 inch teach pendant or mobile terminal Web APP | ||
Pose repeatability per ISO 9283 | ±0.05mm | ||
Axis movement | Working range | Maximum speed | |
Base | ±175° | ±120°/s | |
Shoulder | ﹢85°/﹣265° | ±120°/s | |
Elbow | ±160° | ±180° | |
Wrist1 | ﹢85°/﹣265° | ±180°/s | |
Wrist2 | ±175° | ±180°/s | |
Wrist3 | ±175°(Optional ±360°) | ±180°/s | |
Typical TCP speed | 1.5m/s | ||
Features | IP classification | IP54 (IP65 Optional) | |
Noise | ＜65db | ||
Robot mounting | Any orientation | ||
I/O Ports | DI 16 DO 16 | ||
AI 2 AO 2 | |||
High speed pulse input 2 | |||
Tool I/O power supply | 24V/1.5A | ||
Physical | Footprint | 190mm | |
Weight | ≈40kg | ||
Operating temperature | 0-45℃ | ||
Operating humidity | 90%RH (non-condensing) | ||
Materials | Aluminium、Steel |
